Advantages of Products:
Equipped with the Lingguang K1 3D Reconstruction Module and a high-performance planning host, Argus integrates multi-line LiDAR, 4-eye vision technology, and self-developed neural network algorithms to achieve full-process automation—from spatial digitalization to the generation of operational instructions.
The system boasts a 1.2 cm relative accuracy and 3 cm absolute accuracy, supporting 360° full-field-of-view mobile scanning. Leveraging a rapid computing power of 15 minutes per unit, it automatically completes component recognition, process planning, and path optimization. Through 1:1 global visual simulation, it restores construction details, enables scene simulation and interference detection, and automatically calculates and outputs the robot's operational coverage after each plan. Ultimately, it generates a directly executable construction scheme, achieving seamless synergy between "Real-scene Perception — Intelligent Planning — Robot Execution."

High Precision:With 3 cm absolute accuracy, Argus achieves millimeter-level restoration of both the working surface and the spatial structure.

High Efficiency:A rapid planning efficiency of 15 minutes per unit significantly compresses the preparation cycle for on-site construction.

Intelligent Recognition:Leveraging AI for semantic component recognition, the system automatically generates comprehensive construction process schemes for the working surface.

Versatile Application:Featuring an IP54 protection rating and a wide operating temperature range, Argus is perfectly adapted to complex and demanding construction site environments.

Main Specifications

Technical Specifications: Lingguang K1 3D Reconstruction Module:

Product Model Lingguang K1Total Operating Time1.5 hRepeatability2 cm
Weight1 kgPower Input14.4 VPower SupplyCartridge Battery / External Power Supply
Operating Temperature-20 ℃ ~ 50 ℃Internal StorageTF Card 256 GB

Battery Capacity28.8 WhPower Consumption< 20 W

*The relevant data comes from the application test of Fangshi Technology engineering



Technical Specifications: High-performance Planning Host:

Dimensions450 * 360 * 210 mmNetwork ConnectivityWired Ethernet Port / Supports Wi-Fi Wireless ConnectionPlanning Efficiency15 min per unit (Includes scanning + cropping + task planning)
Weight15 kgPower InputDC 24 VData InterfaceUSB 2.0 / USB 3.0 / Ethernet Port
Charging Time3 hBattery Life3 h

Power Consumption120 WBattery Capacity896 Wh(24 V 18 Ah)

*The relevant data comes from the application test of Fangshi Technology engineering
